Modular Formwork
MODULOCK
Modular formwork combining robustness, safety, and speed of execution. Integrated locking mechanisms eliminate loose parts and enable quick, secure panel assembly.
Technical characteristics
- Pression admissible
- 40 kN/m²
- Châssis
- Acier ou aluminium haute qualité
- Peau coffrante
- Contre-plaqué filmé bouleau 15 mm
- Passages de tige
- 4
- Poids 250×1500 mm
- 13 kg (alu) / 25 kg (acier) — 4 verrous
- Poids 500×1500 mm
- 20 kg (alu) / 39 kg (acier) — 4 verrous
- Poids 750×1500 mm
- 27 kg (alu) / 52 kg (acier) — 5 verrous
- Poids 1000×1500 mm
- 34 kg (alu) / 65 kg (acier) — 5 verrous
Documentation
Photos
Need a quote for MODULOCK?
Response from our technical team within 24h — no obligation.
